The Senvion
4xm Series
Introducing our new 4XM wind turbine platform, which is optimised for higher yields at low-wind sites with hub heights of up to 140 metres. Our innovative design uses off-the-shelf parts from top suppliers and local supply chain integration. With an oprating temperature range of -10 to +49.5°C, our platform meets all the Indian grid code requirements. Trust the proven technology of Senvion to power your wind energy investment.
| Nominal Power(KW) | 4200 |
| Cut in wind speed (m/s) | 3.0 |
| Cut in wind speed (m/s) | 20.0 |
| Nominal wind speed (m/s) | 11.0 |
| Operating Temperature range (°C) | -10 to +49.5 |
| Survival Temperature (°C) | -20 to +50 |
| Nominal Power(Hz) | 50 |
| Converter type | Partial converter DFIG |
| Generator | Double-fed induction generator (DFIG) |
| Generator protection class | IP 54 |
| Wind Class | IEC S III C |
|---|---|
| Type Testing | IEC61400-22/IECRE OD 501 |
| Diameter (m) | 160.0 |
| Rotor area (m2) | 20,108 |
| Power control | Electrical pitch system |
| Length (m) | 78.5 |
| Profile Type | ReT 78.5 |
| Material | GFRP |
| Type | Tubular steel tower |
| Height | 140m |
